v1.0 Visual Flow Builder Conditional Reply : A ChatPion Add-On
Available on :

Shop

Key Features

Use conditional logic based on system and custom fields
Arithmetic and string operators support
Support for multiple conditions
Respond based on a single match or on all conditions matching

How to Use

Using this condition add-on, you can build a condition and rules-based messenger bot that can talk to people intelligently. For example, if the user is male, the bot will call him Mr. On the other hand, if the user is Female, the bot will call her Miss/Mrs. And if the system already has the email number of a specific user, the bot will inform the user that the system already has the email number. Contrarily, if the system doesn’t have the email number of a specific user, the bot will ask for the email number from the user.

To build a condition and rules based messenger bot, you have to use an element called condition that will work as the entry point of the conditional conversation.

Let’s see how to build condition and rules-based messenger bot.

First, go to the editor of the visual Flow Builder. Now add the trigger element to the editor. After that, double-click on the trigger element to add data. Instantly, a form field will appear on the left side of the editor. Now enter ‘condition’ as the keyword for the bot we are going to build. Now click on the ok button. If a user writes ‘condition’ in the messenger, the bot will start.

Trigger element

Now connect the trigger element to the Start Bot Flow. Now double-click on the Start Bot Flow and a form field will appear on the left side of the editor. Give a title for the bot in the title field. For example, I write ‘condition demo’ in the title field. Others fields are optional. You can keep them blank. Now click on the ok button.

Start bot Flow

Now add the condition element by dragging and dropping and connect it with Start Bot Flow. Now double-click on the condition element. Instantly, a form field will appear on the left side of the editor. At the top of the form field, you will see two radio buttons-- All Match and Any Match. And you have to select All Match or Any Match. Note that if you select All Match, all the conditions have to be true to evaluate the expression. On the other hand, if you select Any Match, at least one condition has to be true to evaluate the expression.

Since we will configure only one condition, you can select any of them.

All match, any match

Then you will see the system field and the custom field. Both the system field and the custom field contain initial fields to configure conditions. Of course, by clicking on the plus sign next to the system field and custom field, you can add more fields to configure conditions on them. Of course, you can remove extra condition by clicking remove button.

add and remove condition

Let's set a condition to check if the user is male or female and send messages accordingly:

Click on the Variable field and a drop-down menu of the different variables will appear. Now you have to select a variable. Likewise, you have to select an operator from the operator field and a value from the value field.

I select Gender as the variable, and Equal(=) as the operator, and Male as the value. Now I click on the ok button to insert data to the condition element.

configure a condition male and female

On the condition element, you will see two sockets – True and False. If the condition evaluates to true, the message connecting to the True socket will be sent. Contrary, if the condition evaluates to false, the message connecting to the False socket will be sent.

Well, now add a text element and connect it to the socket called True. Then write a message addressing the user as Mr. the message that will be sent to the male users.

Likewise, add another text element and connect it to the False socket and write a message, addressing the user as Miss/Mrs, the message that will be sent to the female users.

condition false or true male or female

Now add a button element and connect it to both text elements. Well, write a button text and select new postback as the button type and click the ok button. Instantly, a new postback element connected to the button element will appear. Now give a title for the new postback.

add button

Now I will set another condition to see whether the system has the email address of the user or not. If the system has the email address of a user, the bot will inform the user that the updated information will be sent to the email address. On the other hand, if the system doesn’t have the email address of a specific user, the bot will ask for the email address from the user.

Let’s set a condition to check if the system has the email address of a specific user or not and send messages accordingly:

Add condition element and connect it to the new postback element. After that, click on the condition element to configure a condition. If you configure one condition, it doesn’t matter whether you select All Match or Any Match.

Like before, select Email as the variable and Has Value as the operator. And click on the ok button. That’s all. The condition is set.

first condition for email

Now add two text element and connect them to the true and false sockets of the condition element. Now click on the text element connecting to the true element and write a text message to inform the user that the updated information will be emailed to the user.

text message for true email

Then click on the other text element connecting to the false socket and write a message to inform the user that the system doesn’t have the email address and tell the user to click on a quick reply button to send the email address.

text message for false email

If the condition becomes true, the text message connecting to the True socket will be sent. On the other hand, if the condition becomes false, the text message connecting to the False socket will be sent. That is if the system has the email address of a specific user, the bot will inform the user that the updated information will be sent. And if the system doesn’t have the email address of a user, the bot will ask for the email user.

Now add a quick reply button and connect it to the text element connecting to the false socket. Double-click on the quick reply element, select email as the Quick Reply type and click on the ok button. With the reply button, the bot will collect the email address from the user.

condition becomes false or true

Now click on the save button or press Ctrl + s on the keyboard to save your bot.

If everything is ok, the bot will work accordingly. That is, if the user is male, the bot will address him as Mr and if the user is female, the bot will address her as Mrs/Miss. Moreover, if the system has the email address of a user, the bot will inform the user that updated information will be emailed to the user and if the system doesn’t have the email address of a specific user, the bot will ask for the email address of the user.

Now let’s see how the bot does work:

usage of the bot

I write condition in the messenger. The message matches the keyword of the condition-based bot we have made and the first condition of the bot start. The condition checks if I am male or female. It finds out that I am male and sends me the text message that addresses me as Mr. After that I click on the yes button, and the second condition starts. It checks if the system has my email address and finds out that the system doesn’t have my email address. So it asks me for my email number.

    No review found.




4 Comments Login to comment

  • You should allow the condition flow to have sub condition. As result may not only TRUE or FALSE, there are condition with multiple condition as well such like Highest, High, Middle, Low, Lowest. So we need sub condition to match back and link to the right flow.

  • I want to know if I can do what I want to do with the conditions
    The user enters the flow and it verifies if he has a tag, if the tag does not exist the bot tags the user and it sends a custom message, if when verifying the bot detects that the tag exists it does not send the message or it sends a new complementary one.

    I also want to use this logic for the buttons, if the user presses 5 times the bot sends the same flow 5 times, what I would like is to have a condition if the user presses the button the bot sends the message, if the user presses it again the bot does not send any more, also with an action to indicate in how many minutes the user can receive the same message again.

    I hope you can guide me on what I want to do.

  • its not work
    can you explain more about this feature
